Spina Bifida General Principles

Definition



1. Spinal dysraphism



Failure of the neural tube to close (i.e. spina bifida + failure of neural tube development)



May see one of 5 telltale skin defects

- tail

- skin dimpling

- sacral pit

- hair tuft

- lipoma



Myelodysplasia: Any developmental defect of the spinal cord



2. Spina Bifida Cystica



Vertebral laminae absent with prolapse of neural elements



A.  Myeloschisis / Myelocoele

- neural plate material spread out over the surface (most severe form)



B.  Myelomeningocoele

- prolapse of cord & dura in defect (commonest)



C.  Meningocele

- prolapse of dura only

- usually no neurological deficit



3. Spina Bifida Occulta



Congenital spinal disorder where the two halves of posterior arches fail to fuse leading to bony abnormality

- defect is hidden

- may have diastematomyelia

- seen in 5-10% of radiographs in normal population

- not really related to spina bifida cystica and probably not prevented by folate



Epidemiology



1 / 1000 live births

- varies with geographic location

- Ireland, England, Wales - 5/1000

- Australia & USA 1/1000



1:20 with one affected sibling

1:10 with second affected sibling



Girls > boys



Aetiology



Multifactorial nature

- polygenic inheritance with teratogenic enviromental factors



Decreased RBC folate associated with increased risk

- avoid folate antagonists

- folate taken prior to conception reduces rate of spina bifida by 70%

- need to take before first month of pregnancy

- 0.4 mg per day normally

- 4mg per day if have a previous child with SBC



Pathogenesis



Early problem 26th gestational day (24-28)



Two theories

A. Failure of neural tube to close

B.  Initially closed tube which reopens due increased intraluminal pressure



The latter theory is favoured & explains other defects such as diastematomyelia etc



Prenatal Screening



Should be able to detect 90% fetus with an exposed neural defect

- small skin covered defects may be missed



Maternal alphafetoprotein increased

- test at 16-20 weeks

- detects 90% of spina bifida

- will justify other investigations

- amniocentesis (spontaneous abortion risk 1:200)



Ultrasound

- vaginal at 10-12 weeks will identify anencephaly & some spina bifida

- standard 16-18 weeks identify anencephaly & 80% spina bifida



Management of early detection

- deliver by C section to avoid contamination by vaginal flora

- secondary infection which then can lead to loss of level



NHx



Survival

- without repair nearly 100% will die

- especially in pre-antibiotic day

- increase survival to 50% at 25 years

- antibiotics / selective closure / shunting



Neurology

- not static & there is often a decline during childhood especially first 4 years

- 60% have neurological deficiency in upper limb

- this is due to syrinx / Arnold Chiari / hydrocephalus



Function

- only 30% are functionally independent as adults

- only 30% will have full or part-time jobs

- 65% will have normal intelligence



Wheelchair

- 100% if L1 or L2 or higher

- 80% if L3, L4, L5



Modified Asher & Olson Classification



Lowest level at which Grade 3 power is available i.e. antigravity power



Thoracic: no grade 3 strength in lower leg muscles

L2: hip flexion

L3:      knee extension

L4:      knee flexion

L5:      ankle dorsiflexion

Sacral: ankle plantarflexion



i.e. L4 and below are most likely to walk



Clinical Features



1. Hydrocephalus



Incidence 90%

- of these 80% will require shunt

- inserted at time of the defect closure



IQ normal if no hydrocephalus



Must constantly be on lookout for blocked shunt

- deteriorating neurological function

- bulging fontanelle

- poor muscle function



2. Hydromyelia / Syringomelia / Syrinx



Incidence 50%

- related to hydrocephalus

- fourth ventricle communicates with the central canal of cord

- increased hydrocephalus pushes fluid into cord



Leads to

- increased lower limb paralysis & back pain

- progressive scoliosis

- weak upper extremities with increased tone



Usually settles with V-P shunt



May need drainage prior to spinal procedure



3. Arnold - Chiari Malformation: (Type II in 90%)



Displacement of medulla into cervical canal

- cerebellar tonsils herniated below foramen magnum on MRI



Symptoms

- periodic apnea

- stridor

- weak / absent cry

- nystagmus

- upper extremity spasm & weakness



May resolve with shunt / if not then surgically decompress



4. Tethered Cord



Attachment of cord to meningocoele sac

- prevents normal upward migration of the cord during growth

- almost universal to some degree



Only small number have symptoms

- buttock & posterior thigh pain

- increased spasticity & weakness in lower extremities

- progressive scoliosis the classic presentation is progressive

- cavus foot deformity in young child

- rapid deterioration in quadriceps power in teenager



Surgical release will halt progression but not restore function



5. Urinary Complications



One of major causes of morbidity & mortality in childhood from renal failure



Causes

- incontinence

- hydronephrosis

- recurrent UTI



Management

- intermittent catheterisation

- bladder augmentation



6. Skin anaesthesia



Pressure sores major problem with casts

- hip spicas should always include feet



7. Latex Allergy



IgE mediated



Should always provide latex free operating environment

- assume allergy and prevent development



Can screen with RAST (radioallergosorbent test) / skin test / IgE assay

- IgE assay most sensitive & specific



8. Fractures



Classic exam scenario / clinical photo

- supracondylar femoral fracture is commonest



Often present late

- picture of infection (redness, swelling, warmth)



Treat with removable splints for short time as get very stiff



9. Upper Extremity Function



60% have abnormality of UL function

- usually weakness with increased tone



Risk factors

- high level

- multiple shunt revisions (ie cerebral damage from hydrocephalus)

- syrinx etc



10.  Orthopaedic Deformity



Causes

- muscle imbalance 2° to UMN or LMN lesion

- intrauterine posture

- habitual posture after birth

- congenital malformation (eg club foot)

- arthrogryposis



Problems

- scoliosis

- hip FFD / Dislocation

- Knee hyperextension / flexion contracture / valgus

- teratological CTEV

- cavus foot

- charcot foot

- ulceration



Orthopaedic



Goals



1.  Ambulation

- level dependent



2. Hips

- reduce hips if unilateral / low level / walk

- different to CP as not painful



3. Foot

- keep shoeable & plantigrade

- even if in wheelchair

- avoids ulcers and amputation



4.  Spine

- 80% develop scoliosis



5.  Prevent pressure areas



Always manage in spina bifida clinic



Muscle charting

- should start 24 hours after birth



1/3 Complete LMN & loss of sensation & bowel control below affected level



1/3 Complete lesion at some level but distal segment of cord preserved

- mixed picture of intact DTR & spasticity



1/3 Incomplete & some movement & sensation preserved



Levels



L1 Level



Muscles

- iliopsoas grade 2 or better / some weak hip flexion



Position

- Hip flexed, abducted & ER



Ambulation

- HKAFO - hip knee ankle foot orthosis

- RGO - reciprocating gait orthosis, when one hip flexes the other extends

- adults usually wheelchair bound



L2 Level



Muscles

- iliopsoas, sartorius & adductors grade 3 or better

- hip flexion & some adduction



Position

- hip flexed and adduction

- FFD of hip may develop



Ambulation

- most ambulate as children in HKAFO

- FFD may need to be corrected first

- adults usually choose wheelchair



L3 Level



Muscles

- quadriceps grade 3



Position

- hip flexed & adducted

- knee extended

- Hip subluxation & dislocation common due to unopposed hip adduction & flexion



Ambulation

- usually household ambulators

- grade 4 quadriceps - 80% community ambulators / 98% household ambulators

- grade 3 quadriceps -  need KAFO to walk & 88% in wheelchair

- patients with quads & good abductors can ambulate without aids



L4 Level



Muscles

- medial hamstring grade 3

- Tibialis anterior 3 or better

- quadriceps grade 5



Position

- hip flexed & adducted

- knee extended

- ankle in varus due to T anterior



Ambulation

- walk in AFO



Surgery often required to maintain hip & knee extension / foot plantigrade



L5 Level



Muscles

- lateral hamstrings >=3

- G medius >=2

- T posterior >=3



Position

- calcaneovalgus or calcaneus foot

- need T anterior to T Achilles transfer age 3 to prevents foot drop gait



Ambulation

- 95% community ambulators throughout life



Sacral Level



Muscles

- Gastroc/Soleus >/=2

- G medius >/=3

- G maximus >/=3



Position

- clawing of toes & cavus foot from intrinsic minus



Ambulation

- usually brace free but may need special shoes

- ie arch supports



At high risk of heel ulcers due to foot imbalance / calcaneus / nil S1 protective sensation
