Vertical Shear

Vertical shear



Definition



Unstable injuries

Complete disruption of both the anterior and posterior ring



5 - 20% of pelvic fractures



Mechanism



Axial load

Motor vehicle accident

Fall from height



Pathology



Anterior ring

- pubic symphysis disruption

- fracture of the superior and inferior pubic ramus

- fracture acetabulum



Posterior ring

- fracture sacrum / SI joint / ilium



Initial Management



Femoral steinman pin + 20lb weight to reduce vertical displacement

Anterior external fixation to pelvis



Vert shear inital management





Definitive Management



Verticla shearLumbosacral fixation

Lumbosacral fixation with SI screw - triangular osteosynthesis



Vert shear CTVertical shear fixation



Posterior stabilisation critical



Reduction

- closed

- open



Options

- sacro-iliac screws

- trans-sacral trans-iliac screws

- trans-iliac posterior tension band plating

- lumbosacral fixation



Anterior stabilisation



Pubic symphysis plates

Percutaneous ramus screws



Results



Griffin et al J Orthop Trauma 2006

- 62 patients with vertical shear fractures treated with SI screws

- increased failure rate in vertical sacral fractures compared sacro-iliac joint dislocation



Tisano et al OTA Int 2020

- 20 vertical shear fractures

- 12 sacro-iliac dislocations and 8 vertical sacral fractures

- no failures in sacro-iliac dislocations

- failure in 4/8 vertical sacral fractures

- 3/4 failures of vertical sacral fracture fixed with single SI screw
